ChipFastenersTechnical documentation
CF-RN109-0315
M3 x 0.5 steel rivet nut
MaterialSteel
ThreadM3 x 0.5
Body length L9 mm
Technical specifications
| Order code | CF-RN109-0315 |
|---|---|
| Brand | ChipFasteners |
| Series | CF-RN109 |
| Product type | Rivet nut |
| Material | Steel |
| Thread | M3 x 0.5 |
| Body length L | 9 mm |
| Head style | Reduced |
| Body style | Round, knurled |
| End style | Open |
| Grip range | 0.5 to 1.5 mm |
| Mounting hole | 4.8 mm |
| Dimension A | 5.5 mm |
| Body dimension D | 4.7 mm |
| Head dimension B | 5.4 mm |
| Head thickness K | 0.4 mm |
Product overview
M3 x 0.5 rivet nut for 0.5 to 1.5 mm panel thickness. Steel construction with a reduced head and round, knurled body. Open end; overall length 9 mm. Mounting hole 4.8 mm.
Documents & drawings
Dimensional drawing 1chipfasteners.com
